강조하다
AC refrigerant recharge machine
,gas filling system for AC
,refrigerant charging station with warranty
-
조건새로운
-
적용 가능한 산업제조 공장
-
무게 (kg)300
-
전시실 위치아무 것도
-
비디오 출입 검사제공
-
기계 시험 보고사용할 수 없습니다
-
핵심 부품에 대한 보증1년
-
핵심 부품모터, 펌프
-
종류압축기
-
보증1년
-
판매 후 서비스 제공해외에 있는 기계 서비스용 엔지니어
-
결의0.1g
-
전압380V/50HZ
-
냉장료R22/R410A/R407C/R134A
-
모델 부정CM8600 R32 냉매 충전 시스템
-
정확성±0.5%
-
진공도5파~10파
-
충전 속도60~260g/초
-
적용에어컨, 정수기, 냉동고, 냉장고
-
항구상하이 닝보 톈진 청도
-
원래 장소진주, 중국
-
브랜드 이름CM
-
인증CE, ATEX
-
모델 번호CM8600
-
최소 주문 수량1 단위
-
가격$20,400.00/units 1-2 units
-
포장 세부 사항나무 케이스, CM8600 냉매 충전 기계용 팔레트
-
공급 능력50 유닛 / 유닛마다 달
AC Recharge Machine Gas Filling System
AC Recharge Machine Gas Filling System
Product Specifications
| Attribute | Value |
|---|---|
| Condition | New |
| Applicable Industries | Manufacturing Plant |
| Weight (KG) | 300 |
| Video Outgoing-Inspection | Provided |
| Warranty of Core Components | 1 Year |
| Core Components | Motor, Pump |
| Type | COMPRESSOR |
| Warranty | 1 Year |
| After-sales Service | Engineers available to service machinery overseas |
| Resolution | 0.1g |
| Voltage | 380V/50HZ |
| Refrigerant Compatibility | R22/R410A/R407C/R134A |
| Model No | CM8600 R32 refrigerant charging system |
| Precision | ±0.5% |
| Vacuum Degree | 5Pa~10Pa |
| Charging Speed | 60~260g/s |
| Application | Air conditioner, water dispenser, freezer, refrigerator |
| Port | Shanghai Ningbo Tianjin Qingdao |
Product Overview
CM8600 Dual System Refrigerant Charging Machine for Refrigerator Assembly Line
The CM86 refrigerant charging machine is specially designed for high-speed refrigerant charging in production lines. It features exceptional charging speed, high accuracy, and multiple functions. Compatible with CFC, HFC, and HC refrigerants, this machine can be customized to meet specific requirements.
Key Features
- CNC technology enables precise data processing with accurate and easy operation
- Charging/filling capability for liquid gases including R134a, R22, R407C, R410A (customizable for R600a, R290, R32)
- Siemens PLC with colorful touch screen control system
- High-accuracy flow sensors provide resolution of 1~0.1g
- Wonfulay pneumatic booster ensures stable pressure and large charging quantity supply
- Continuous charging capacity up to 99999g with charging rate of 60g~260g
- Automatic prompt function when refrigerant in cylinder is low
- Adjustable vacuum time and inspection leak time
- Wonfulay filling gun improves charging/filling speed
- Wonfulay high vacuum pump achieves quick vacuum of 5~10Pa
- Multiple functions: vacuum, inspection leak, charging/filling, refrigerant recovery
- Repeat filling accuracy ≤ ± 0.5%
- Portable design for easy movement
Product Images
Front View
Control Panel
Side View
Components
Filling Interface
Internal Components
Pneumatic System
Vacuum Pump
